Techtop 1.5kW 2 Pole Single Phase Electric Motor 240V | TML 90S | 2855 RPM

What is the Techtop TML 90S 1.5kW 2 Pole motor commonly used for?

This motor is commonly used on water pumps, air compressors, industrial blowers, ventilation fans, conveyor systems, agricultural machinery and workshop equipment requiring reliable high-speed performance.

What speed does this motor operate at?

The motor operates at approximately 2855 RPM under full load. Its 2 pole design provides high rotational speed, making it ideal for fast-running industrial equipment.

Does this motor require a 240V power supply?

Yes. The motor operates from a standard 240V 50Hz single-phase power supply.

What type of starting system does this motor use?

The motor features a Capacitor Start / Capacitor Run (CSCR) design, providing high starting torque and smooth running performance.

Does this motor include thermal overload protection?

Yes. It is fitted with a manual reset thermal overload protector to help prevent overheating and extend motor life.

What capacitors does this motor use?

This motor uses a 200µF 300V start capacitor and a 40µF 450V run capacitor. Paddle Wholesale stocks replacement Motor Start Capacitors and Motor Run Capacitors.

Can this motor replace an existing single-phase motor?

Yes. As long as the power output, frame size, shaft dimensions, mounting configuration and operating speed match your existing motor, it is an excellent replacement.

Why choose a 2 pole motor?

A 2 pole motor provides higher operating speed than 4 or 6 pole motors, making it ideal for pumps, compressors, fans and machinery requiring maximum RPM.

Do you offer Australia-wide shipping?

Yes. Paddle Wholesale offers fast Australia-wide shipping, expert technical support, competitive trade pricing and worldwide delivery on selected products.

• Brand: Techtop
• Model: TML 90S
• Power Output: 1.5kW
• Poles: 2
• Speed: 2855 RPM
• Voltage: 240V Single Phase
• Frequency: 50Hz
• Frame Size: 90S
• Mounting: B3 Foot Mount
• Motor Series: TML Capacitor Start / Capacitor Run
• Construction: Aluminium
• Cooling: Totally Enclosed Fan Cooled (TEFC)
• Protection Rating: IP55
• Insulation Class: F (Class B Rise)
• Duty Rating: S1 Continuous Duty
• Service Factor: 1.0
• Full Load Current: 8.3A
• Full Load Torque: 5.01Nm
• Efficiency: 80.2%
• Power Factor: 0.99
• Maximum Slip: 4.8%
• Noise Level: 75 dB(A)
• Vibration Limit: 1.3mm/sec
• Start Capacitor: 200µF 300V
• Run Capacitor: 40µF 450V
• Bearing Type: NSK 6205ZZ / 6205ZZ C3
• Direction of Rotation: Bi-directional
• Colour: RAL 9005 (Jet Black)
• Thermal Protection: Manual Reset Overload
• Motor Weight: 14kg
• Approvals: C-Tick, CE
• IEC Standards: IEC 60034 & IEC 60072

• Powerful 1.5kW Output – Delivers dependable performance for demanding industrial, commercial and agricultural applications.
• High-Speed 2 Pole Design – Operates at approximately 2855 RPM, making it ideal for pumps, compressors, fans and industrial machinery.
• Heavy-Duty 90S Aluminium Frame – Provides superior durability, excellent cooling and long service life.
• Capacitor Start / Capacitor Run (CSCR) – Produces excellent starting torque with smooth, efficient running performance.
• TEFC Construction – Totally Enclosed Fan Cooled design protects the motor against dust and moisture.
• IP55 Protection – Suitable for demanding workshop, industrial and agricultural environments.
• Premium NSK Bearings – Ensures smooth operation, reduced vibration and extended bearing life.
• Manual Reset Thermal Overload Protection – Helps protect the motor from overheating.
• S1 Continuous Duty Rated – Built for reliable continuous operation.
• Built to IEC Standards – Manufactured to IEC 60034 and IEC 60072 international standards.
