Techtop TML 71B-2 0.55kW Single Phase Electric Motor – 2 Pole 2790RPM 240V
Techtop TML 71B-2 0.55kW Single Phase Electric Motor – 2 Pole 2790RPM 240V
Australian owned
Fast Dispatch
Worldwide Shipping
Expert Support
The Techtop TML 71B-2 is a reliable and high-speed 0.55kW single phase electric motor designed for industrial, workshop, and machinery applications. Featuring a durable aluminium housing and capacitor start/capacitor run operation, this 2 pole motor delivers efficient 2790RPM performance with smooth operation and dependable starting torque.
Designed to operate on a standard 240V single-phase power supply, the TML 71B-2 is suitable for pumps, fans, belt-driven equipment, workshop machinery, and general replacement motor applications. Browse our range of single-phase electric motors and electric motors for more industrial-motor solutions.
Featuring IP55 protection, Class F insulation, and manual reset overload protection, this motor is built for continuous-duty industrial environments and long-term reliability.
Faqs
Faqs
What applications is the TML-71B-2 motor suitable for?
The TML-71B-2 is suitable for pumps, fans, compressors, belt-driven equipment, workshop machinery, and general industrial applications.
Is this a single phase motor?
Yes, this is a 240V single phase electric motor with capacitor start and capacitor run operation.
What speed does this motor operate at?
This motor operates at approximately 2790RPM and features a 2 pole configuration.
What type of protection does this motor have?
The motor features IP55 protection and manual reset overload protection for reliable industrial operation.
What type of bearings are used?
This motor uses high-quality NSK ball bearings with 6202ZZ / 6202ZZ C3 bearing configuration.
Is this motor suitable for continuous operation?
Yes, the TML series motors are designed for S1 continuous-duty industrial applications.
What capacitors does this motor use?
The motor uses a 75μF start capacitor and a 16µF run capacitor for reliable starting and smooth operation.
Can this motor be used as a replacement motor?
Yes, the TML-71B-2 is commonly used as a replacement electric motor for compatible industrial and workshop equipment.
Specification
Specification
Model: TML-71B-2
Power Output: 0.55kW
Pole: 2 Pole
Voltage: 240V
Frequency: 50Hz
Speed: 2790 RPM
Full Load Current: 3.4 Amps
Frame Size: 71B
Construction: Aluminium
Motor Type: TEFC - Capacitor Start / Capacitor Run
Protection Rating: IP55
Insulation Class: Class F with Class B Rise
Duty Rating: S1 Continuous Duty
Thermal Protection: Manual Reset Overload
Full Load Torque: 1.9Nm
Starting Current Ratio: 5.8
Starting Torque Ratio: 2.78
Break Down Torque Ratio: 1.7
Noise Level: 73 dB(A)
Bearing Brand: NSK
Bearing Type: Ball / Ball
Bearing Size: 6202ZZ / 6202ZZ C3
Weight: 7.0kg
-
Start Capacitor: 75μF / 250VAC
Run Capacitor: 16µF / 450VAC
IEC Standard: IEC 60034 & 72
Features and benefits
Features and benefits
- Durable aluminium motor housing
- Reliable capacitor start and capacitor run operation
- High-speed 2 pole 2790RPM performance
- Designed for continuous-duty industrial applications
- IP55 rated for protection against dust and moisture
- Manual reset overload protection for added safety
- Class F insulation with Class B temperature rise
- Smooth and efficient motor operation
- Suitable for pumps, fans, compressors, and workshop machinery
- Compact and reliable replacement motor solution
- High-quality NSK bearings for long service life
- Designed for standard 240V single phase power supplies
